Lenses for Long-Wave Infrared (LWIR) Cameras for 8-12 µm

LWIR Manual Focus Lens

Shape Optics provides LWIR Manual Focus Lenses for thermal imaging systems operating in the 8–12 µm wavelength range. These lenses allow operators to adjust image sharpness through direct mechanical focusing, making them suitable for applications requiring occasional focus adjustment at different observation distances.

Available in various focal lengths and optical configurations, our manual focus lenses support compatible uncooled infrared detectors and can be integrated into industrial inspection, portable thermal imaging, surveillance, and research systems.

LWIR Manual Focus Lens

Overview

Flexible Focus Adjustment

Enables precise manual control of focus to adapt to different object distances and scene requirements.

Cost-Effective Solution

Simpler mechanical design reduces cost while maintaining reliable optical performance.

Wide Application Compatibility

Suitable for various LWIR systems including thermal cameras, industrial monitoring, and handheld devices.

Reliable Performance

Engineered for stable imaging performance across standard operating environments.

How Does Manual Focus Lens Work?

An LWIR manual focus lens uses a mechanical focusing mechanism to adjust the position of the optical elements relative to the infrared detector. By rotating the focus ring or adjusting the designated focusing mechanism, operators can optimize image sharpness for the required observation distance.

Unlike fixed-focus optical systems, manual focusing allows the lens to accommodate different working distances without requiring an electronic focus motor or controller.

For installations where the observation distance remains relatively constant, the lens can be focused during setup and left at the selected position. Where observation distances change, operators can readjust focus manually to obtain a sharper thermal image.

Manual Focus vs Motorized Focus

Manual focus lenses are suitable for systems where direct access to the lens is available and frequent remote adjustment is unnecessary. For applications requiring electronic focus adjustment or remote operation, explore our LWIR Motorized Focus Lens solutions.

LWIR Manual Focus Lens

Key Considerations for Lens Selection

Selecting an LWIR manual focus lens requires evaluating the detector format, required observation distance, optical performance, and focusing mechanism.

Parameter Selection Considerations
Focal Length Determine the required field of view and target observation distance.
Detector Compatibility Match the lens to the detector resolution, pixel pitch, and active image size.
F-number (F/#) Select an appropriate aperture for the detector and imaging requirements.
Focus Adjustment Range Confirm the minimum object distance and supported focusing range.
Focus Mechanism Consider focus-ring accessibility, adjustment precision, and locking requirements.
Optical Performance Evaluate MTF, distortion, transmission, and image quality at relevant focus positions.
Mechanical Interface Review lens mounting dimensions, back focal distance, and installation space.
Operating Environment Consider temperature changes, vibration, and mechanical stability.

Explore our complete range of LWIR lens solutions for different detector formats and imaging requirements. For applications requiring stable focus across temperature changes, consider our LWIR Athermal Lens solutions.

Applications in Infrared Imaging

LWIR manual focus lenses are suitable for thermal imaging applications requiring direct focus adjustment during installation, inspection, or operation.

  • Handheld Thermal Inspection: Allow operators to adjust image focus when inspecting equipment, structures, or components at different working distances
  • Building and Infrastructure Inspection: Support thermal observation of building envelopes, electrical installations, and mechanical systems.
  • Laboratory Thermal Imaging: Provide adjustable focus for infrared experiments, component evaluation, and controlled testing environments.
  • Portable Surveillance Systems: Enable manual focus adjustment for transportable thermal cameras used at different observation distances.
Handheld Thermal Inspection
Thermal Building Inspection Survey
Laboratory Thermal Imaging Research
Portable Thermal Surveillance Control Room

Request Quote

Need a custom LWIR lens?

Tell us your detector, focal length, and requirements — our engineering team will support your design.
