Lenses for Long-Wave Infrared (LWIR) Cameras for 8-12 µm

LWIR Motorized Focus Lens

Shape Optics provides LWIR motorized focus lenses for thermal imaging systems operating in the 8–12 µm wavelength range. These lenses enable electronic focus adjustment through integrated motor mechanisms, allowing operators to control image sharpness remotely without manually adjusting the lens.

Designed for compatible uncooled infrared detectors, our motorized focus solutions support applications requiring automated operation, adjustable observation distances, and integration with thermal imaging cameras, surveillance equipment, and embedded optical systems.

LWIR Motorized Focus Lens

LWIR Motorized Focus Lens Overview

Remote Focus Control

Enables focus adjustment via software or controller, eliminating the need for manual operation.

High Precision Adjustment

Provides accurate and repeatable focusing for improved imaging performance.

Ideal for Integrated Systems

Designed for seamless integration into thermal cameras, surveillance systems, and embedded platforms.

Enhanced Operational Efficiency

Improves workflow efficiency by enabling fast and automated focus adjustments in real-time applications.

How Does Motorized Focus Work?

A motorized focus lens uses an electrically driven mechanism to adjust the position of optical elements within the lens assembly. The movement changes the optical focus position, allowing the thermal imaging system to achieve clear images at different observation distances.

Unlike manual focus lenses, which require physical adjustment, motorized focusing enables electronic control through a compatible controller or camera system.

Depending on the lens configuration, focus adjustment can be operated through software commands, electronic interfaces, or an integrated imaging system. This makes motorized lenses suitable for applications requiring remote operation or repeated focus changes.

Advantages of Motorized Focusing

  • Remote Operation: Adjust focus without direct physical access to the lens.
  • Repeatable Positioning: Support controlled focus adjustments for different observation distances.
  • System Integration: Enable focus control through compatible electronic interfaces.
  • Operational Flexibility: Support thermal imaging applications where observation distances change.

For applications where electronic focus control is unnecessary, explore our LWIR Manual Focus Lens solutions.

LWIR Motorized Focus Lens

Key Considerations for Lens Selection

Selecting a suitable motorized lens requires evaluating optical specifications alongside motor control, focusing accuracy, and integration requirements.

Parameter Selection Considerations
Focal Length Determine the required field of view and observation distance.
Detector Compatibility Match detector resolution, pixel pitch, and active image size.
F-number (F/#) Select an appropriate optical aperture for the detector.
Focus Adjustment Range Confirm the minimum object distance and supported focusing range.
Motor Control Interface Verify the electrical interface, controller compatibility, and supported commands.
Positioning Accuracy Evaluate focus adjustment precision, repeatability, and backlash where specified.
Power Requirements Confirm operating voltage, current, and electrical integration requirements.
Mechanical Integration Review mounting dimensions, installation space, and motor clearance.
Environmental Conditions Consider operating temperature, vibration, and mechanical reliability.

Shape Optics provides standard and customized LWIR optical solutions for different thermal imaging requirements. Explore our LWIR lens range or contact our engineering team to discuss detector compatibility, motor control interfaces, and optical specifications.

Motorized focusing is particularly useful in thermal imaging systems requiring remote operation, electronic control, or frequent focus adjustment.

  • Remote Surveillance Systems: Enable operators to adjust image focus remotely when observing targets at different distances.
  • Automated Industrial Inspection: Support electronically controlled focus adjustment in thermal inspection equipment and automated production environments.
  • Robotic and Autonomous Platforms: Allow compatible robotic imaging systems to adjust focus without direct manual intervention.
  • Integrated Thermal Imaging Systems: Support embedded infrared cameras and OEM imaging platforms requiring electronic focus control.
Remote Surveillance Control Room
Automated Industrial Thermal Inspection
Robotic Thermal Inspection Platform
Integrated Thermal Imaging Controller

Request Quote

Need a custom LWIR lens?

Tell us your detector, focal length, and requirements — our engineering team will support your design.
